Light Pole Poster LED Display |
Module Specifications |
Part Number |
I60-3SOA |
I60-4SOA |
I60-5SOA |
I60-6SOA |
Pixel Pitch (mm) |
3mm |
4mm |
5mm |
6mm |
LED Configuration |
1R1G1B SMD2020 |
1R1G1B SMD2020 |
1R1G1B SMD2727 |
1R1G1B SMD2727 |
Module size |
192X96mm |
128x128mm |
160x160mm |
192x96mm |
Module Resolution |
64x32dot |
32x32dot |
32x32dot |
32x16dot |
Cabinet Specifications |
Cabinet Size |
820x1600x80mm |
820x1600x80mm |
800x1600X120mm |
768x1600X130mm |
Cabinet Resolution |
256X448dot |
192X320dot |
160x256dot |
128x224dot |
Cabinet Weight |
40kg |
40kg |
40kg |
40kg |
Main Parameter |
Pixel Density |
111111dot/m² |
62500dot/m² |
40000dot/m² |
27777dot/m² |
Size |
60 inches |
60 inches |
60 inches |
60 inches |
IP Rating (front/back) |
IP65 |
IP65 |
IP65 |
IP65 |
Scanning Mode |
16S |
8S |
8S |
8S |
Maximum Brightness |
4500CD/m² |
4500CD/m² |
5000CD/m² |
5000CD/m² |
Viewing Angle |
120° |
120° |
120° |
120° |
View Distance |
>4m |
>5m |
>6m |
>7m |
Gray Scale |
14bit |
14bit |
14bit |
14bit |
Display Scale |
16.7M |
16.7M |
16.7M |
16.7M |
Ave.Power Consumption |
150W |
150W |
150W |
150W |
Refresh Frequency |
≥1920HZ |
≥1920HZ |
≥1920HZ |
≥1920HZ |
Environmental |
OUTDOOR |
OUTDOOR |
OUTDOOR |
OUTDOOR |
Brightness Adjustment |
0 – 100 levels adjustable |
Control Mode |
Asynchronous Control |
Support Input |
Composite,S-Vido,Component,VGA,DVI,HDMI,HD_SDI |
Operation Power |
AC100/240 50/60HZ |
Operating Temperature |
– 20℃~+70℃ |
Operating Humidity |
10~90% RH |
Operating Life |
100,000hours |
Intelligent Control:
HD-display,energy-saving; wifi module, charging interface and GPS inside; distant and large-scale control available; smart monitor and equipped with smoke, humidity, temperature detectors; interactive voice-and-video response access.
High IP Level:
With front/back IP level 65/54.
Fashion Design:
Super thin cabinet, lightweight, stylish shape with technological and art aesthetic feeling.
Advantages:
Time and labor-saving.
The convenience of installation and maintenance, low cost.
Application:
Community, walking street, school, hospital, roadside, park, supermarket, parking lot, metro station, hotel, gas station, automobile 4s shop, tourist attraction, bus station, etc.
